Briggs and Stratton Vanguard 5HP Vertical Crankshaft Engine Spare Parts

Briggs&Stratton uk | Briggs and Stratton Vertical 2-7 HP Engine Parts | Briggs and Stratton Vertical 2-7HP Overhead Valve OHV Engine Parts |  Briggs and Stratton Vanguard 5HP Vertical Crankshaft Engine Spare Parts

Vanguard 5HP Vertical Crankshaft (Rotary Lawnmower type) Engine Spare Parts


The Briggs and Stratton Vanguard 5HP vertical crankshaft engine was fitted to heavy duty walk behind lawnmowers.
It is overhaed valve with fuel tank on the left (viewed from behind) and an oil dipstick onthe right.
Model numbers 104772 & 104777

992424 Mower Cover


Quantity:

992424 Mower Cover

Price: 19.20 (16.00 Excluding VAT at 20%)

Approx shipping weight 600g

Walk behind mower cover.
Protects against most weather conditions.
Fits walk behind mowers up to 22"
Width 55cm
Length 142cm
Height to handlebar 119cm


272147 Briggs and Stratton Single Cylinder Vanguard Repair Manual


Quantity:

272147 Briggs and Stratton Single Cylinder Vanguard Repair Manual

Price: 18.99

Approx shipping weight 680g

Repair manual for all single cylinder Vanguard engines

Covers all you need to know!


992304 Spark Plug


Quantity:

992304 Spark Plug

Price: 4.39 (3.66 Excluding VAT at 20%)

Approx shipping weight 50g

RC12YC Spark plug for all OHV engines


19567S (was 992355 and 6095E) Spark Plug Wrench


Quantity:

19567S (was 992355 and 6095E) Spark Plug Wrench

Price: 6.30 (5.25 Excluding VAT at 20%)

Approx shipping weight 120g

16mm/19mm Spark plug box wrench for 992304 spark plug


992210 Start Care Kit


Quantity:

992210 Start Care Kit

Price: 12.24 (10.20 Excluding VAT at 20%)

Approx shipping weight 0.1kg

Briggs and stratton Start Care oil change kit. Includes 2 x 0.6 litres of oil (one bottle for an oil change and the other for through season top ups), 100ml bottle of fuel fit additive and deep sided oil drain tray.


992380 Fuel Fit Additive


Quantity:

992380 Fuel Fit Additive

Price: 4.19 (3.49 Excluding VAT at 20%)

Approx shipping weight 130g

Briggs and Stratton Petrol additive for all 4 stroke and 2 stroke petrol engines
Prevents fuel deterioration during periods of non-use and generally aids engine efficiency
Essential for correct winter storage of lawnmowers etc.

100 ml, treats 10 litres of fuel.


992423 Oil Drain Pump


Quantity:

992423 Oil Drain Pump

Price: 19.20 (16.00 Excluding VAT at 20%)

Approx shipping weight 1kg

Oil drain pump kit. Includes vacuum pump, oil container, tubing etc.
Allows draining oil without tipping machine.


992015 Throttle control


Quantity:

992015 Throttle control

Price: 12.84 (10.70 Excluding VAT at 20%)

Approx shipping weight 105g

Throttle control and cable to fit many applications
1.35m long. End can be bent to suit
Negative action(Control pushed to fast, shortens inner wire)


992016 Throttle control


Quantity:

992016 Throttle control

Price: 12.72 (10.60 Excluding VAT at 20%)

Approx shipping weight 105g

Throttle control and cable to fit many applications
1.35m long. End can be bent to suit
Positive action(Control pushed to fast, lengthens inner wire)


690798/691044 Cable Clamp & Screw


Quantity:

690798/691044 Cable Clamp & Screw

Price: 7.80 (6.50 Excluding VAT at 20%)

Approx shipping weight 10g

Clamp and screw, throttle cable


491950 Air Filter


Quantity:

491950 Air Filter

Price: 23.34 (19.45 Excluding VAT at 20%)

Approx shipping weight 340g

Air filter cartridge for 5HP Vanguard vertical crankshaft engine.
Approx 14cm long x 7cm high


272218 Pre Filter


Quantity:

272218 Pre Filter

Price: 5.64 (4.70 Excluding VAT at 20%)

Approx shipping weight 10g

Foam pre filter for 491950 air filter cartridge


492932S Oil Filter


Quantity:

492932S Oil Filter

Price: 12.30 (10.25 Excluding VAT at 20%)

Approx shipping weight 300g

Briggs and Stratton spares Oil filter for many pressure lubricated engines
Approx 6cm tall x 7.5cm diameter(at base)


491367S Fuel Cap


Quantity:

491367S Fuel Cap

Price: 12.78 (10.65 Excluding VAT at 20%)

Approx shipping weight 80g

Fuel Cap for 5HP Vanguard engine
External tank thread diameter approx 57mm


691370 Strainer


Quantity:

691370 Strainer

Price: 13.32 (11.10 Excluding VAT at 20%)

Approx shipping weight 20g

Fuel strainer for plastic fuel tank
Approx 55mm long. Fits tank opening approx 38mm diameter


395051R Briggs and Stratton Fuel Tube


Quantity:

395051R Briggs and Stratton Fuel Tube

Price: 4.80 (4.00 Excluding VAT at 20%)

Approx shipping weight 20g per 20cm

Fuel tube for most applications

Sold in units of 20cm. Multiple purchases will be supplied in one total length
Use with 710075 clamps.(sold seperately)


710075 Fuel Tube clamp


Quantity:

710075 Fuel Tube clamp

Price: 3.18 (2.65 Excluding VAT at 20%)

Approx shipping weight 10g

Plated fuel tube hose clamp
Fits 11mm O/D fuel tube 395051


691038 Fuel Tube Clamp - Black


Quantity:

691038 Fuel Tube Clamp - Black

Price: 3.12 (2.60 Excluding VAT at 20%)

Approx shipping weight 10g

Black fuel tube clamp. Fits 12mm O/D fuel hose
(Slightly smaller than 95162)


791850 Fuel Tube Clamp - Green


Quantity:

791850 Fuel Tube Clamp - Green

Price: 3.12 (2.60 Excluding VAT at 20%)

Approx shipping weight 10g

Green fuel tube clamp. Fits fuel tube over 12mm O/D
(Slightly larger than 691038)


19200E Briggs and Stratton Engine Speed Tachometer


Quantity:

19200E Briggs and Stratton Engine Speed Tachometer

Price: 19.28 (16.07 Excluding VAT at 20%)

Approx shipping weight 40g

RPM tachometer to accurately set engine speed
Easy to use and compact. Complete with instructions and wallet
Suits any engine


715226 Starter Rewind


Quantity:

715226 Starter Rewind

Price: 96.66 (80.55 Excluding VAT at 20%)

Approx shipping weight 740g

Rewind assembly for 5HP Vangaurd engines.
Incudes flywheel cup for converting older metal pawl starters
Mounting bolt hole centre pitch circle approx 165mm diameter


280399S (also 66734) Rope


Quantity:

280399S (also 66734) Rope

Price: 5.70 (4.75 Excluding VAT at 20%)

Approx shipping weight 35g

3.5mm diameter recoil rope for quantum engines.
Approx 2.4m long white
Replaces shorter rope 66734


393152 Rubber Grip


Quantity:

393152 Rubber Grip

Price: 5.82 (4.85 Excluding VAT at 20%)

Approx shipping weight 40g

Rubber recoil grip with plastic insert suits engines where grip returns to the engine


695708 Starter Gear


Quantity:

695708 Starter Gear

Price: 7.50 (6.25 Excluding VAT at 20%)

Approx shipping weight 20g

16 tooth plastic starter gear for most starter motors


691641 Pin


Quantity:

691641 Pin

Price: 3.54 (2.95 Excluding VAT at 20%)

Approx shipping weight 10g

Retaining pin. For pin retained started gears


696540 Starter Drive


Quantity:

696540 Starter Drive

Price: 26.88 (22.40 Excluding VAT at 20%)

Approx shipping weight 180g

Electric starter motor drive kit for most earlier starter motors
Plastic drive gear and pin type retainer.(also suits early models without return spring & cage)


690664 Screw


Quantity:

690664 Screw

Price: 4.08 (3.40 Excluding VAT at 20%)

Approx shipping weight 10g

Screw 10-32 thread x 3/8" long (0.19" thread diapmeter - approx 4.8mm)
Used in many places where a small short screw is required such as pressed steel muffler guards, covers and shields etc.


272131 Rocker Gasket


Quantity:

272131 Rocker Gasket

Price: 9.18 (7.65 Excluding VAT at 20%)

Approx shipping weight 20g

Rocker cover gasket. Vanguard 5HP Vertical


399781S Oil seal


Quantity:

399781S Oil seal

Price: 6.60 (5.50 Excluding VAT at 20%)

Approx shipping weight 30g

399781S Crankshaft oil seal, for 5HP Vertical crankshaft engine
This is used for both the upper and lower oil seals


590454 Armature


Quantity:

590454 Armature

Price: 49.20 (41.00 Excluding VAT at 20%)

Approx shipping weight 250g

Ignition armature, please order 790848 if one is fitted to your engine.


796964 Ignition Armature


Quantity:

796964 Ignition Armature

Price: 50.70 (42.25 Excluding VAT at 20%)

Approx shipping weight 350g

Electronic ignition armature magneto coil for 5HP Vanguard engines
Please note that there has been a design change to this unit. The new one may not resemble your original exactly but is correct and will fit the engine.


692390 Stop Wire


Quantity:

692390 Stop Wire

Price: 3.78 (3.15 Excluding VAT at 20%)

Approx shipping weight 20g

Stop wire. Approx 42cm long


692310 Stop Switch


Quantity:

692310 Stop Switch

Price: 5.94 (4.95 Excluding VAT at 20%)

Approx shipping weight 10g

Stop switch.


19203 Puller - Large


Quantity:

19203 Puller - Large

Price: 12.00 (10.00 Excluding VAT at 20%)

Approx shipping weight 230g

Flywheel puller for larger engines
Distance between outer hole centres approx 72mm
Includes long and short bolt sets


222698S Briggs & Stratton Spare Parts Flywheel key


Quantity:

222698S Briggs & Stratton Spare Parts Flywheel key

Price: 2.76 (2.30 Excluding VAT at 20%)

Approx shipping weight 5g

Flywheel key to fit most engines
Approx. 14mm long x 3mm x 4mm


692193 Crankshaft Woodruff key


Quantity:

692193 Crankshaft Woodruff key

Price: 2.34 (1.95 Excluding VAT at 20%)

Approx shipping weight 5g

Half moon woodruff key to fit crankshaft extension of most small Briggs and Stratton engines applications
No 505 - 5/32" x 5/8" (approx 4mm thick x 15mm long)


7015894SM Woodruff Key


Quantity:

7015894SM Woodruff Key

Price: 2.10 (1.75 Excluding VAT at 20%)

Approx shipping weight 5g

#605 Woodruff Key 3/16" x 5/8" used on 25mm diameter crankshaft engines


692191 3/16


Quantity:

692191 3/16" Key

Price: 5.58 (4.65 Excluding VAT at 20%)

Approx shipping weight 30g

Key, crankshaft pulley 3/16" (Approx 4.75mm) square section x 37mm long


0025X6MA Engine Mounting Bolt


Quantity:

0025X6MA Engine Mounting Bolt

Price: 2.88 (2.40 Excluding VAT at 20%)

Approx shipping weight 10g

Engine mounting bolt. Self tap 3/8" x 1". Suitable for mounting engine onto steel or alluminium chassis up to 1/4" thickness.


Unlisted parts page
Unlisted parts page
Unlisted parts page

Briggs&Stratton uk | Briggs and Stratton Vertical 2-7 HP Engine Parts | Briggs and Stratton Vertical 2-7HP Overhead Valve OHV Engine Parts |  Briggs and Stratton Vanguard 5HP Vertical Crankshaft Engine Spare Parts

Feedback for has been compiled from 651 reviews.

Dates:Product:Score:Customer Comment:
Date:Product:

499706 Rewind Starter Assembly

Score:
Customer Comment:

Easy to navigate website and simple ordering proceedure

Date:Product:

271139S Air Filter Gasket 698717 Head Gasket 692307 Exhaust Muffler 992210 Start Care Kit

Score:
Customer Comment:

Everything I needed, fast delivery, original parts. No complaints, have used them several times and will again.

Date:Product:

496894S Air Filter Cartridge 272403S Pre-Filter

Score:
Customer Comment:

Fast delivery. Easy website. Very professional. Briggs clearly know all the details

Date:Product:

992244 (Was 992233) Briggs and Stratton Quantum Service kit

Score:
Customer Comment:

Good and quick service great product

Date:Product:

270026 Carb Diaphragm 692206 Diaphragm Spring 27355S Manifold Gasket

Score:
Customer Comment:

Good service, but expensive delivery

Date:Product:

692218 Gasket, Crankcase 391483S Oil seal

Score:
Customer Comment:

The ordered parts arrived in time and in good condition.

Date:Product:

272996 (was 272410) Carb Gasket 272538S Carb Diaphragm 692237 Exhaust Gasket

Score:
Customer Comment:

excellent customer service, nothing too much trouble, would recommend them with complete confidence

Date:Product:

84005207 Camshaft (793880 Old Number) 697110 Crankcase Gasket 795387 Seal 594201 (was591334 and 796031) Filter

Score:
Customer Comment:

spoke to Michael in parts department told him i had purchased parts earlier but had missed a part out when ordering said he would try his best to get it to me following day low and behold part came following morning great customer service will certainly use them again

Date:Product:

19069 Puller - Small 690254 Air Vane Governor Spring 691859 Idle Governor Spring

Score:
Customer Comment:

Everything was as ordered would recommend certainly buy again

Date:Product:

593576 Instart Charger

Score:
Customer Comment:

Quick efficient service

Date:Product:

692189 Grommet 992300C Spark Plug 270579S Air Filter 691633 Fuel Tank Spacer

Score:
Customer Comment:

Everything ! Parts for ancient mower, delivered overnight at sensible price. Ordering more. Thank you.

Date:Product:

992015 Throttle control

Score:
Customer Comment:

Parts arrived a few days after ordering. Not the cheapest out there when delivery factored in but at least you know the part is going to fit without too much fiddling around versus a generic replacement.

Date:Product:

692734 Fuel Solenoid (Les 04/09/20) 276781 Briggs and Stratton Single Cylinder OHV Repair Manual 272403S Pre-Filter

Score:
Customer Comment:

Extremely helpful Prompt response

Date:Product:

691292 Governor Spring 491588S Genuine Briggs Spares Air Filter

Score:
Customer Comment:

Good packaging and quick service.

Date:Product:

795629 Air Filter Gasket (was 272653S) 491588S Genuine Briggs Spares Air Filter

Score:
Customer Comment:

All good thanks

Date:Product:

795477 Sprint / Classic / Quattro Carburettor assy (was 794161 & 498811)

Score:
Customer Comment:

Quick delivery easy to access also sent me a catalouge

Date:Product:

690994 Seal 690987 O Ring Seal #1 597338 (was 808656) Fuel Pump 690988 Seal (Andy 08/09/20) 691917 Seal (Andy 08/09/20)

Score:
Customer Comment:

Easy to order and quick delivery

Date:Product:

594575 Air Filter Cover

Score:
Customer Comment:

Their efficiency was first class. The part was located and shipped with no delay and reached me as soon as was humanly possible. Well done and thanks.

Date:Product:

694395 Primer Bulb

Score:
Customer Comment:

Right parts jolly fast!

Date:Product:

799866 Carburettor 691292 Governor Spring

Score:
Customer Comment:

Item exactly as described and not a cheap copy, arrived in good time which meant that I was able to get my mower up and running again within a couple of days of it breaking down. Many thanks.

©copyright 2019 Mower Bits Ltd. All rights reserved
(see terms and conditions)

spacer image
