Replacement Engines and shortblocks

New Briggs and Stratton replacement engines and shortblocks

(Appearance of covers etc may differ from illustration)

New Replacement Engine Crankshaft quoted lengths :-

The lengths quoted for engine crankshafts are taken from the engines mounting face where it is bolted to the equipment, not the length emerging from the engine.

550 Horizontal Crankshaft Engine 3/4 #1


Quantity:

550 Horizontal Crankshaft Engine 3/4 #1


Price: 232.80 (Including VAT at 20%)

Approx shipping weight 15kg

3.5HP OHV horizontal crankshaft engine fitted to cylinder lawnmower, rotorvator, cement mixer and other applications
Crankshaft 3/4" diameter with 3/16" keyway
0831321114H1BF7001

Click for engine line drawings pdf


Mounting dimensions pop-up

550 Horizontal Crankshaft Engine 5/8


Quantity:

550 Horizontal Crankshaft Engine 5/8


Price: 247.20 (Including VAT at 20%)

Approx shipping weight 15kg

3.5HP OHV horizontal crankshaft engine fitted to cylinder lawnmower, rotorvator, cement mixer and other applications
Crankshaft 5/8" diameter with 3/16" keyway 0831321040F1BF1001

Click for engine line drawings pdf

Mounting dimensions pop-up

550 Horizontal 6:1 Reduction Horiz engine


Quantity:

550 Horizontal 6:1 Reduction Horiz engine


Price: 312.00 (Including VAT at 20%)

Approx shipping weight 18kg

3.5HP Horizontal crankshaft engine with 6:1 reduction gearbox
3/4" gearbox output shaft with keyway
0831521141H1BH7001

Click for engine line drawings pdf

Additional dimensional information popup

Briggs and Stratton 800 OHV Engine


Quantity:

Briggs and Stratton 800 OHV Engine


Price: 264.00 (Including VAT at 20%)

Approx shipping weight 18kg

Overhead valve horizontal crankshaft engine fitted to cylinder lawnmower, rotorvator, chipper shredder and other applications. Integral fuel tank and controls
Crankshaft 3/4" (Approx 19mm) diameter with 3/16" keyway. 1263023236H8R7001

Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs and Stratton 800 OHV Engine 1


Quantity:

Briggs and Stratton 800 OHV Engine 1"


Price: 298.80 (Including VAT at 20%)

Approx shipping weight 18kg

Intek overhead valve horizontal crankshaft engine fitted to cylinder lawnmower, rotorvator, chipper shredder and other applications. Integral fuel tank and controls
1" Diameter crankshaft. Threaded 1263020779H8R7001

Click for engine line drawings pdf

Mounting dimensions pop-up

2:1 APTO 800 Series Engine


Quantity:

2:1 APTO 800 Series Engine


Price: 280.80 (Including VAT at 20%)

Approx shipping weight 18kg

Overhead valve horizontal crankshaft 2:1 APTO. Replaces 5HP engine on some rotorvators, and other applications. Integral fuel tank and controls. Low oil auto cut out system.
Crankshaft 3/4" (Approx 19mm) diameter with 3/16" keyway. 2:1 reverse direction auxilliary pto drive parallel with main shaft
1263921235B8R7001

Click for engine line drawings pdf

Auxilliary shaft position pop-up

Briggs and Stratton 6.5HP OHV Vanguard Engine


Quantity:

Briggs and Stratton 6.5HP OHV Vanguard Engine


Price: 355.20 (Including VAT at 20%)

Approx shipping weight 18kg

Vanguard overhead valve horizontal crankshaft engine fitted to cylinder lawnmower, rotorvator, chipper shredder and other applications. Integral fuel tank and controls. Low oil auto cut out system
Crankshaft 3/4" (Approx 19mm) diameter with 3/16" keyway. 13L3320316F8AV7001

Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs and Stratton 6.5HP OHV Vanguard Engine E/S


Quantity:

Briggs and Stratton 6.5HP OHV Vanguard Engine E/S


Price: 514.80 (Including VAT at 20%)

Approx shipping weight 18kg

Vanguard overhead valve horizontal crankshaft engine with electric starter. Fitted to cylinder lawnmower, rotorvator, chipper shredder and other applications. Integral fuel tank and controls. Low oil auto cut out system
Battery charge output
Crankshaft 3/4" (Approx 19mm) diameter with 3/16" keyway. 13L3370128F8AV7001

Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs and StrattonVanguard 6.5HP 6:1 Reduction Engine


Quantity:

Briggs and StrattonVanguard 6.5HP 6:1 Reduction Engine


Price: 460.80 (Including VAT at 20%)

Approx shipping weight 18kg

Vanguard overhead valve horizontal crankshaft engine with 6:1 reduction gearbox as fitted to many low rpm applications. Integral fuel tank and controls. Low oil auto cut out system
Crankshaft 3/4" (Approx 19mm) diameter with 3/16" keyway
13L3520319F8BB7001
Click for engine line drawings pdf

Gearbox dimensions pop-up

Briggs and Stratton 6.5HP Vanguard OHV Engine 2:1


Quantity:

Briggs and Stratton 6.5HP Vanguard OHV Engine 2:1


Price: 384.00 (Including VAT at 20%)

Approx shipping weight 18kg

Vanguard overhead valve horizontal crankshaft engine with 2:1 geared reduction(approx 1800 top rpm)
Counter clockwise rotation viewed from the crankshaft side of the engine
Integral fuel tank and controls
Output shaft 3/4" (Approx 19mm) diameter with 3/16" keyway
Output shaft 1.775" from centre of gearbox/engine crankshaft
13L3620125F8BB1001



Click for output shaft position drawing pdf


Briggs and Stratton 6.5HP I/C OHV Vanguard Engine 1


Quantity:

Briggs and Stratton 6.5HP I/C OHV Vanguard Engine 1"


Price: 356.40 (Including VAT at 20%)

Approx shipping weight 18kg

Intek overhead valve horizontal crankshaft engine fitted to cylinder lawnmower, rotorvator, chipper shredder and other applications. Integral fuel tank and controls. Low oil auto cut out system
Crankshaft 1" (Approx 25mm) diameter with 1/4" keyway. 13L3320313F8AV7001

Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs and Stratton 6.5HP Vanguard Engine Tapered Shaft


Quantity:

Briggs and Stratton 6.5HP Vanguard Engine Tapered Shaft


Price: 355.20 (Including VAT at 20%)

Approx shipping weight 18kg

Vanguard overhead valve horizontal crankshaft engine fitted to Generators and other applications. Integral fuel tank and controls. Low oil auto cut out system
Tapered crankshaft 13H3320114B8AV7001


Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs and Stratton 6HP OHV Intek Engine Threaded Shaft


Quantity:

Briggs and Stratton 6HP OHV Intek Engine Threaded Shaft


Price: 316.80 (Including VAT at 20%)

Approx shipping weight 18kg

Intek overhead valve horizontal crankshaft engine fitted to cylinder lawnmower, rotorvator, chipper shredder and other applications. Integral fuel tank and controls. Low oil auto cut out system
Crankshaft 5/8" x 18 UNF Threaded 12S4320035F8BG1001

Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs and Stratton 6HP OHV Intek Engine 6:1 Reduction


Quantity:

Briggs and Stratton 6HP OHV Intek Engine 6:1 Reduction


Price: 408.00 (Including VAT at 20%)

Approx shipping weight 18kg

Intek overhead valve horizontal crankshaft engine with 6:1 reduction gearbox fitted to aplication requiring reduced output RPM. Integral fuel tank and controls
Crankshaft 3/4" Diameter 1220523549H8R1001

Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs & Stratton 1150 OHV Engine Tapered


Quantity:

Briggs & Stratton 1150 OHV Engine Tapered


Price: 351.60 (Including VAT at 20%)

Approx shipping weight 20kg

Briggs and Stratton 1150 series engine
Tapered crankshaft
Rewind start. 2.8l integral fuel tank

1502020132H8WW7001

Briggs & Stratton 1150 OHV Engine 1


Quantity:

Briggs & Stratton 1150 OHV Engine 1"


Price: 456.00 (Including VAT at 20%)

Approx shipping weight 20kg

Briggs and Stratton 1150 series engine
1" straight crankshaft with 1/4" keyway
Rewind start. 2.8l integral fuel tank

15T2120160F8BG1001

Briggs and Stratton 9HP Vanguard OHV E/S Engine


Quantity:

Briggs and Stratton 9HP Vanguard OHV E/S Engine


Price: 684.00 (Including VAT at 20%)

Approx shipping weight 26kg

9HP Overhead valve Vanguard horizontal crankshaft engine with electric start
10A regulated charging circuit. 1" diameter keyed output crankshaft
19L2370319F1AX7001

Click for engine line drawings pdf


Briggs and Stratton Vanguard 10HP Engine


Quantity:

Briggs and Stratton Vanguard 10HP Engine


Price: 530.40 (Including VAT at 20%)

Approx shipping weight 24kg

10HP Vanguard OHV horizontal crankshaft engine
1" diameter keyed crankshaft
19L2320314F1AX7001

Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs and Stratton Intek 10HP Engine 6:1


Quantity:

Briggs and Stratton Intek 10HP Engine 6:1


Price: 537.60 (Including VAT at 20%)

Approx shipping weight 24kg

10HP Intek OHV horizontal crankshaft engine
1" diameter keyed crankshaft
6:1 reduction gearbox

2053520195H1H7001

Click for engine line drawings pdf

Mounting dimensions pop-up

Briggs and Stratton Intek 10HP Engine E/S


Quantity:

Briggs and Stratton Intek 10HP Engine E/S


Price: 681.60 (Including VAT at 20%)

Approx shipping weight 32kg

10HP Intek OHV horizontal crankshaft engine
1" diameter keyed crankshaft
Electric start with 12v charging output
2053371185H1H7001

Click for engine line drawings pdf

Mounting dimensions pop-up

695154 Spacer kit


Quantity:

695154 Spacer kit


Price: 25.08 (Including VAT at 20%)

Approx shipping weight 240g

Engine mounting spacer kit. For 19 & 20 series horizontal crankshaft engine when replacing older side valve engine
Raises crankshaft position by 1.05"

Vanguard 13HP Horizontal Engine


Quantity:

Vanguard 13HP Horizontal Engine


Price: 789.60 (Including VAT at 20%)

Approx shipping weight 26kg

Vanguard 13HP Horizontal crankshaft engine with oil guard. Rewind start
2454320235B2BB1001


Click for engine line drawings pdf


Vanguard 13HP Horizontal E/S Engine


Quantity:

Vanguard 13HP Horizontal E/S Engine


Price: 979.20 (Including VAT at 20%)

Approx shipping weight 28kg

Vanguard 13HP Horizontal crankshaft engine with oil guard, elec start and 16A charging circuit
2454370284B2BB1001

Click for engine line drawings pdf


Briggs and Stratton 14HP Vanguard Engine


Quantity:

Briggs and Stratton 14HP Vanguard Engine


Price: 1,333.20 (Including VAT at 20%)

Approx shipping weight 31kg

14HP Vanguard V Twin horizontal crankshaft engine.
1" diameter crankshaft. Electric start with battery charge output
Supplied with fuel tank but without exhaust system
2964470003H1K0001

Click for engine line drawings pdf


Briggs and Stratton 16HP Vanguard Engine


Quantity:

Briggs and Stratton 16HP Vanguard Engine


Price: 1,231.20 (Including VAT at 20%)

Approx shipping weight 31kg

16HP Vanguard V Twin horizontal crankshaft engine.
1" diameter crankshaft. Electric start with 16A charging circuit
Supplied withoutbut without fuel tank and exhaust system
3054470117B1T1001

Click for engine line drawings pdf


Briggs and Stratton 18HP Vanguard Engine


Quantity:

Briggs and Stratton 18HP Vanguard Engine


Price: 1,264.80 (Including VAT at 20%)

Approx shipping weight 31kg

18HP Vanguard V Twin horizontal crankshaft engine.
1" diameter crankshaft. Recoil start
Supplied withoutbut without fuel tank and exhaust system
3564420369B1HH1001

Click for engine line drawings pdf


Briggs and Stratton 18HP Vanguard Engine E/S


Quantity:

Briggs and Stratton 18HP Vanguard Engine E/S


Price: 1,392.00 (Including VAT at 20%)

Approx shipping weight 31kg

18HP Vanguard V Twin horizontal crankshaft engine.
1" diameter crankshaft. Electric start with 16A Regulated charging output.
Pressure, filtered lubrication with pressure cut out switch
Supplied without without fuel tank and exhaust system
3564470123B1T1001

Click for engine line drawings pdf


Briggs and Stratton 18HP Vanguard Engine E/S & Rewind


Quantity:

Briggs and Stratton 18HP Vanguard Engine E/S & Rewind


Price: 1,614.00 (Including VAT at 20%)

Approx shipping weight 31kg

18HP Vanguard V Twin horizontal crankshaft engine.
1" diameter crankshaft. Rewind and Electric start with 20A Regulated charging output.
Pressure, filtered lubrication with pressure cut out switch
Supplied with integral fuel tank but not exhaust system (see below)
3564470374F1K1001

Click for engine line drawings pdf


807752 Exhaust System


Quantity:

807752 Exhaust System


Price: 154.86 (Including VAT at 20%)

Approx shipping weight 1kg

Exhaust system for new Vanguard twin cylinder 16HP & 18HP vertical crankshaft engine
Illustration of system.

496238 Short Block


Quantity:

496238 Short Block


Price: 908.40 (Including VAT at 20%)

Approx shipping weight 17kg

Vanguard twin horizontal crankshaft 35 CIC. 1" daimeter crankshaft

Briggs and Stratton Vanguard 22HP Engine


Quantity:

Briggs and Stratton Vanguard 22HP Engine


Price: 1,594.80 (Including VAT at 20%)

Approx shipping weight 35kg

Horizontal crankshaft 22HP Vanguard twin cylinder engine
1" diameter crankshaft,Recoil Start, supplied without fuel tank or exhaust system (see below)
3864420115G1K1001

Click for engine line drawings pdf


Briggs and Stratton Vanguard 22HP Engine


Quantity:

Briggs and Stratton Vanguard 22HP Engine


Price: 1,694.40 (Including VAT at 20%)

Approx shipping weight 35kg

Horizontal crankshaft 22HP Vanguard twin cylinder engine
1" diameter crankshaft, electric start with 16A charging, supplied without fuel tank or exhaust system (see below)
3864470114B1HH1001

Click for engine line drawings pdf


Briggs and Stratton Vanguard Twin Engine LPG Tapered


Quantity:

Briggs and Stratton Vanguard Twin Engine LPG Tapered


Price: 1,681.20 (Including VAT at 20%)

Approx shipping weight 35kg

Horizontal crankshaft Vanguard twin cylinder engine
tapered crankshaft, electric start with 16A charging, supplied without fuel tank or exhaust system (see below) LPG
3894470110E1HH1001

Click for engine line drawings pdf


808738 Muffler


Quantity:

808738 Muffler


Price: 128.46 (Including VAT at 20%)

Approx shipping weight 3.3kg

Exhaust muffler system for 38 horizontal
Includes manifold, brackets and oil filter side mounted muffler

Briggs and Stratton Vanguard 31HP Engine


Quantity:

Briggs and Stratton Vanguard 31HP Engine


Price: 2,241.60 (Including VAT at 20%)

Approx shipping weight 60kg

31HP Vanguard Big Block V Twin horizontal crankshaft engine
Electric start with 20A Regulated charge alternator. Pressure lubrication with low oil pressure cut out switch
1 1/8" diameter keyed crankshaft
Fuel tank and exhaust system not included (see below)
5434770005G1AD0001
Click here for further information about this engine

Briggs and Stratton Vanguard 35HP Engine


Quantity:

Briggs and Stratton Vanguard 35HP Engine


Price: 2,478.00 (Including VAT at 20%)

Approx shipping weight 60kg

35HP Vanguard Big Block V Twin horizontal crankshaft engine
Electric start with 20A Regulated charge alternator. Pressure lubrication with low oil pressure cut out switch
1 1/8" diameter keyed crankshaft
Fuel tank and exhaust system not included
6134771175B1Ah1001
Click here for further information about this engine

809983 Muffler


Quantity:

809983 Muffler


Price: 206.34 (Including VAT at 20%)

Approx shipping weight 4.5kg

Exhaust muffler kit for 54 & 61 series Vanguard (31HP & 35HP)
Oil filter side outlet

843741 Muffler


Quantity:

843741 Muffler


Price: 209.76 (Including VAT at 20%)

Approx shipping weight 4.8kg

Exhaust muffler kit for 54 & 61 series Vanguard (31HP & 35HP)
Centre outlet

Briggs and Stratton Sprint 450 Engine 62mm


Quantity:

Briggs and Stratton Sprint 450 Engine 62mm


Price: 168.00 (Including VAT at 20%)

Approx shipping weight 12kg

Sprint 500 replacement vertical crankshaft engine complete

Basic engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for Sprint, Classic, Quatro and older engines up to 4HP
Fitted with OPC (deadmans handle) stop control but also includes throttle stop and instructions to disable the brake if required for use with non OPC machines
Prime and pull starting
Crankshaft extension 7/8" diameter x 62mm height from engine mountings(extends approx 50mm from lower engine seal)
10T5020139H1YY7001

Click for engine line drawings pdf


Briggs and Stratton  500E OHV Engine 80mm


Quantity:

Briggs and Stratton 500E OHV Engine 80mm


Price: 172.80 (Including VAT at 20%)

Approx shipping weight 12kg

500E Overhead Valve vertical crankshaft replacement engine complete
Mechanically governed for more power
Fits rotary lawnmower and other vertical crankshaft applications
Suitable upgrade replacement for Sprint, Classic, Quatro and older engines up to 4HP
Fitted with OPC (deadmans handle) stop control
Prime and pull starting
Crankshaft extension 7/8" diameter x 80mm height from engine mountings(extends approx 69mm from lower engine seal)
09P6020015H1YY0001

Click for engine line drawings pdf


Briggs and Stratton  500E OHV Engine 62mm


Quantity:

Briggs and Stratton 500E OHV Engine 62mm


Price: 172.80 (Including VAT at 20%)

Approx shipping weight 12kg

500E Overhead Valve vertical crankshaft replacement engine complete
Mechanically governed for more power
Fits rotary lawnmower and other vertical crankshaft applications
Suitable upgrade replacement for Sprint, Classic, Quatro and older engines up to 4HP
Fitted with OPC (deadmans handle) stop control
Prime and pull starting
Crankshaft extension 7/8" diameter x 62mm height from engine mountings(extends approx 50mm from lower engine seal)
09P6020014H1YY0001

Click for engine line drawings pdf


591292 Lockout Link


Quantity:

591292 Lockout Link


Price: 2.58 (Including VAT at 20%)

Approx shipping weight 10g

Engine brake lockout link. Used to disable the brake where an engine is fitted to an application which does not use a mechanical emergency stop lever. NOT TO BE FITTED WHERE AN ENGINESTOP LEVER IS PRESENT.
"U" Bend at each end for later engines


Briggs and Stratton 700 Series DOV Engine 80mm


Quantity:

Briggs and Stratton 700 Series DOV Engine 80mm


Price: 260.40 (Including VAT at 20%)

Approx shipping weight 16kg

700 Series DOV 6HP vertical crankshaft engine
7/8" diameter crankshaft extending 80mm from mounting face
1008020148H8YY7001

Click for engine line drawings pdf


Briggs and Stratton 700 Series DOV Engine 7/8


Quantity:

Briggs and Stratton 700 Series DOV Engine 7/8" E/S #1


Price: 314.40 (Including VAT at 20%)

Approx shipping weight 17kg

700 Series DOV 6HP vertical crankshaft engine
7/8" diameter crankshaft extending 80mm from mounting face
Electric start with 12v charge output
1008070150H8YY7001

Click for engine line drawings pdf


Briggs and Stratton Quantum 650 Engine 46mm


Quantity:

Briggs and Stratton Quantum 650 Engine 46mm


Price: 249.60 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 650 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 5HP
Fitted with OPC (deadmans handle) stop control but also includes throttle stop and instructions to disable the brake if required for use with non OPC machines
Prime and pull starting
Crankshaft extension 7/8"(22.2mm) diameter x 46mm long from mounting face (Dim A on drawing linked below)
122T020227H1YY7001

Click for engine line drawings pdf


Briggs and Stratton Quantum 650 Engine 62mm


Quantity:

Briggs and Stratton Quantum 650 Engine 62mm


Price: 236.40 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 650 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 5HP
Fitted with OPC (deadmans handle) stop control but also includes throttle stop and instructions to disable the brake if required for use with non OPC machines
Prime and pull starting
Crankshaft extension 7/8"(22.2mm) diameter x 62mm long from mounting face (Dim A on drawing linked below)
124T026952H1YY7001

Click for engine line drawings pdf


Briggs and Stratton Quantum 650 Engine 80mm


Quantity:

Briggs and Stratton Quantum 650 Engine 80mm


Price: 236.40 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 650 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 5HP
Fitted with OPC (deadmans handle) stop control but also includes throttle stop and instructions to disable the brake if required for use with non OPC machines
Prime and pull starting
Crankshaft extension 7/8"(22.2mm) diameter x 80mm long from mounting face (Dim A on drawing linked below)
124T026950H1YY7001

Click for engine line drawings pdf


Briggs and Stratton Quantum 675 Engine 80mm  E/S


Quantity:

Briggs and Stratton Quantum 675 Engine 80mm E/S


Price: 298.80 (Including VAT at 20%)

Approx shipping weight 17kg

Quantum 650 Electric Start replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 6HP
Fitted with OPC (deadmans handle) stop control but also includes throttle stop and instructions to disable the brake if required for use with non OPC machines
Electric and pull starters. 12v charging alternator
Crankshaft extension 7/8"(22.2mm) diameter x 80mm long from mounting face (Dim A on drawing linked below)
126M075060F1YY1001

Click for engine line drawings pdf


Briggs and Stratton Quantum 675 Engine 62mm


Quantity:

Briggs and Stratton Quantum 675 Engine 62mm


Price: 284.40 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 675 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 6HP
Fitted with OPC (deadmans handle) stop control but also includes throttle stop and instructions to disable the brake if required for use with non OPC machines
Prime and pull starting
Crankshaft extension 7/8"(22.2mm) diameter x 62mm long from mounting face (Dim A on drawing linked below)
126T020391H1YY7001

Click for engine line drawings pdf


Briggs and Stratton Quantum 675 Engine 46mm


Quantity:

Briggs and Stratton Quantum 675 Engine 46mm


Price: 270.00 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 675 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 6HP
Fitted with OPC (deadmans handle) stop control but also includes throttle stop and instructions to disable the brake if required for use with non OPC machines
Choke cold starting
Crankshaft extension 7/8"(22.2mm) diameter x 46mm long from mounting face (Dim A on drawing linked below)
126M021005F1YY1001

Click for engine line drawings pdf


Briggs and Stratton Quantum 675 Engine 80mm


Quantity:

Briggs and Stratton Quantum 675 Engine 80mm


Price: 285.60 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 675 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 6HP
Fitted with OPC (deadmans handle) stop control but also includes throttle stop and instructions to disable the brake if required for use with non OPC machines
Prime and pull starting
Crankshaft extension 7/8"(22.2mm) diameter x 80mm long from mounting face (Dim A on drawing linked below)
126M021011F1YY1001

Click for engine line drawings pdf


799983 Short Block


Quantity:

799983 Short Block


Price: 124.80 (Including VAT at 20%)

Approx shipping weight 10kg

Short block for Quantum 12 series engine
80mm 7/8" crankshaft
Includes gaskets required for fitting

222698S Briggs & Stratton Spare Parts Flywheel key


Quantity:

222698S Briggs & Stratton Spare Parts Flywheel key


Price: 2.70 (Including VAT at 20%)

Approx shipping weight 5g

Flywheel key to fit most engines
Approx. 14mm long x 3mm x 4mm
!!<>!!Associated special tools

797521 Gear


Quantity:

797521 Gear


Price: 4.20 (Including VAT at 20%)

Approx shipping weight 50g

Timing gear

Crankcase gasket 692232


Quantity:

Crankcase gasket 692232


Price: 7.44 (Including VAT at 20%)

Approx shipping weight 30g

692232 Crankcase gasket
Required for fitting sump assembly from side APTO Quantum and Intek engines

399781S Oil seal (pto side)


Quantity:

399781S Oil seal (pto side)


Price: 5.64 (Including VAT at 20%)

Approx shipping weight 30g

399781S Oil seal, pto
Required for fitting sump assembly from side APTO Quantum and Intek engines

691952 Oil Seal


Quantity:

691952 Oil Seal


Price: 6.84 (Including VAT at 20%)

Approx shipping weight 10g

Oil seal. Side APTO Shaft

Briggs and Stratton Quantum 675 Engine 25mm x 80mm


Quantity:

Briggs and Stratton Quantum 675 Engine 25mm x 80mm


Price: 262.80 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 675 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 6HP
OPC (deadmans handle) stop control. If fitted to older non OPC complient machines, a safe stop mechanism must be rigged. (kit supplied)
Prime and pull starting
Crankshaft extension 25mm diameter x 80mm long from mounting face (Dim A on drawing linked below)
126M021625F1YY1001

Click for engine line drawings pdf


Briggs and Stratton Quantum 675 Engine 25mm x 62mm


Quantity:

Briggs and Stratton Quantum 675 Engine 25mm x 62mm


Price: 270.00 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 675 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 6HP
OPC (deadmans handle) stop control. If fitted to older non OPC complient machines, a safe stop mechanism must be rigged. (kit supplied)
Prime and pull starting
Crankshaft extension 25mm diameter x 62mm long from mounting face (Dim A on drawing linked below)
126M021026F1YY1001

Click for engine line drawings pdf


Briggs and Stratton Quantum 675 Engine 25mm E/S


Quantity:

Briggs and Stratton Quantum 675 Engine 25mm E/S


Price: 279.60 (Including VAT at 20%)

Approx shipping weight 16kg

Quantum 675 replacement vertical crankshaft engine complete

High quality engine fits rotary lawnmower and other vertical crankshaft applications
Replacement for most engines up to 6HP
OPC (deadmans handle) stop control. If fitted to older non OPC complient machines, a safe stop mechanism must be rigged. (kit supplied)
Electric start with 12v charge output
Crankshaft extension 25mm diameter x 80mm long from mounting face (Dim A on drawing linked below)
126M075662F1YY1001

Click for engine line drawings pdf


691826 Link


Quantity:

691826 Link


Price: 3.00 (Including VAT at 20%)

Approx shipping weight 10g

Engine brake lockout link. Used to disable the brake where an engine is fitted to an application which does not use a mechanical emergency stop lever. Not to be fitted to engines where a stop lever is present.


799984 Short Block


Quantity:

799984 Short Block


Price: 154.80 (Including VAT at 20%)

Approx shipping weight 7kg

Short block assembly
Quantum. Includes gaskets required to transfer items from the original engine.
25mm x 80mm diameter crankshaft tapped 3/8" x 24 UNF

222698S Briggs & Stratton Spare Parts Flywheel key


Quantity:

222698S Briggs & Stratton Spare Parts Flywheel key


Price: 2.70 (Including VAT at 20%)

Approx shipping weight 5g

Flywheel key to fit most engines
Approx. 14mm long x 3mm x 4mm
!!<>!!Associated special tools

Briggs and Stratton Intek  850 OHV Engine 62mm


Quantity:

Briggs and Stratton Intek 850 OHV Engine 62mm


Price: 333.60 (Including VAT at 20%)

Approx shipping weight 16kg

Intek 850 overhead valve vertical crankshaft engine
7/8" diameter crankshaft 62mm
122Q020118H1YY7001

Click for engine line drawings pdf


Briggs and Stratton Intek  850 OHV Engine 80mm


Quantity:

Briggs and Stratton Intek 850 OHV Engine 80mm


Price: 308.40 (Including VAT at 20%)

Approx shipping weight 16kg

Intek 850 overhead valve vertical crankshaft engine
7/8" diameter crankshaft 80mm
122Q020126H1YY7001

Click for engine line drawings pdf


Briggs and Stratton Intek  850 OHV Engine H/F


Quantity:

Briggs and Stratton Intek 850 OHV Engine H/F


Price: 318.00 (Including VAT at 20%)

Approx shipping weight 16kg

Intek 850 overhead valve vertical crankshaft engine
7/8" diameter crankshaft 80mm
Heavy flywheel suitable for applications with blade clutch etc.
122Q020123H1YY7001

Click for engine line drawings pdf


Briggs and Stratton Intek  850 OHV Engine E/S


Quantity:

Briggs and Stratton Intek 850 OHV Engine E/S


Price: 398.40 (Including VAT at 20%)

Approx shipping weight 17kg

Intek 850 overhead valve vertical crankshaft engine
Electric start with 12V battery charge output
7/8" diameter crankshaft 80mm
121S072060F1YY1001

Click for engine line drawings pdf


 Briggs and Stratton Intek  850 OHV Engine 25mm


Quantity:

Briggs and Stratton Intek 850 OHV Engine 25mm


Price: 362.40 (Including VAT at 20%)

Approx shipping weight 16kg

Intek 850 overhead valve vertical crankshaft engine
25mm diameter crankshaft 80mm
121S022025F1YY1001

Click for engine line drawings pdf


 Briggs and Stratton Intek  850 OHV Engine 25mm E/S


Quantity:

Briggs and Stratton Intek 850 OHV Engine 25mm E/S


Price: 380.40 (Including VAT at 20%)

Approx shipping weight 16kg

Intek 850 overhead valve vertical crankshaft engine
25mm diameter crankshaft 80mm
Electric start with 12v battery charge output
121Q072062F1YY1001

Click for engine line drawings pdf


Briggs and Stratton Intek 11.5HP 3115 Rewind Start


Quantity:

Briggs and Stratton Intek 11.5HP 3115 Rewind Start


Price: 558.00 (Including VAT at 20%)

Approx shipping weight 29kg

Overhead valve 11.5HP vertical crankshaft engine

Engine fits ride-on mowers, garden tractors and other vertical crankshaft applications
Comes complete with exhaust but not fuel tank.(see below for optional fuel tank)
Rewind starter. (Picture does not show rewind starter) Earth to stop connections
Crankshaft extension 1" diameter x 3 5/32" long (from engine mounting locations)
Suitable replacement for most 8-10HP applications
2179023148B1CC7001

Click for engine details pdf

Engine dimensions pop-up

Briggs and Stratton 12.5HP 3125 Engine


Quantity:

Briggs and Stratton 12.5HP 3125 Engine


Price: 674.40 (Including VAT at 20%)

Approx shipping weight 26kg

Overhead valve 12.5HP vertical crankshaft engine

High quality engine fits ride-on mowers, garden tractors and other vertical crankshaft applications
Comes complete with exhaust but not fuel tank.(see below for optional fuel tank)
Splash lubrication
Electric start, 9amp alternator and earth to stop connections
Crankshaft extension 1" diameter x 3 5/32" (81mm) long (from engine mounting locations)
Suitable replacement for most 10-13HP applications
2198074028F1CC1001

!Click for engine details pdf

Engine dimensions pop-up

Short Block 697740


Quantity:

Short Block 697740


Price: 300.00 (Including VAT at 20%)

Approx shipping weight 14kg

Short block assembly for model series 21 engine without oil filter
Assembled with crankshaft, camshaft, piston, con rod etc.
Includes gaskets required for transfer of auxilliary parts including cylinder head
We strongly recommend using the appropriate manual 276781 when carrying out this work
Please note: The flywheel bolt torque requirement has been increased to 110ft lbs
19433 Strap Wrench (further down this page) or a similar suitable flywheel holding device must be used in order to safely achieve this torque figure when tightening down the flywheel

222698S Briggs & Stratton Spare Parts Flywheel key


Quantity:

222698S Briggs & Stratton Spare Parts Flywheel key


Price: 2.70 (Including VAT at 20%)

Approx shipping weight 5g

Flywheel key to fit most engines
Approx. 14mm long x 3mm x 4mm
!!<>!!Associated special tools

Briggs and Stratton Intek 12.5HP 3125 Rewind Start


Quantity:

Briggs and Stratton Intek 12.5HP 3125 Rewind Start


Price: 657.60 (Including VAT at 20%)

Approx shipping weight 29kg

Overhead valve 12.5HP vertical crankshaft engine with pressure lubricaion and oil filter

Engine fits ride-on mowers, garden tractors and other vertical crankshaft applications
Comes complete with exhaust but not fuel tank.(see below for optional fuel tank)
Rewind starter. (Picture does not show rewind starter) Earth to stop connections
Crankshaft extension 1" diameter x 3 5/32" long (from engine mounting locations)
Suitable replacement for most 8-10HP applications
2199720145H1CC7001

Click for engine details pdf

Engine dimensions pop-up

Briggs and Stratton Intek 13.5HP 3130 Engine


Quantity:

Briggs and Stratton Intek 13.5HP 3130 Engine


Price: 673.20 (Including VAT at 20%)

Approx shipping weight 26kg

I/C overhead valve 13HP vertical crankshaft engine

High quality engine fits ride-on mowers, garden tractors and other vertical crankshaft applications
Comes complete with exhaust but not fuel tank.(see below for optional fuel tank)
Pressure lubrication with oil filter (not shown of photograph)
Electric start, 9amp alternator and earth to stop connections
Crankshaft extension 1" diameter x 3 5/32" (81mm) long (from engine mounting locations)
Suitable replacement for most 10-13HP applications
21B9774156H1CC7001

Click for engine details pdf

Engine dimensions pop-up

792168 Fuel Tank


Quantity:

792168 Fuel Tank


Price: 55.32 (Including VAT at 20%)

Approx shipping weight 300g

Optional fuel tank for 21 series (10HP &13HP) Intek engines. Complete with fuel line and cap
Requires extended head studs (see below)

790560 Stud


Quantity:

790560 Stud


Price: 9.96 (Including VAT at 20%)

Approx shipping weight 50g

Cylinder head stud for fitting 792168 Fuel tank. 2 required

15.5HP 4155 Intek Vertical Crankshaft Engine


Quantity:

15.5HP 4155 Intek Vertical Crankshaft Engine


Price: 746.40 (Including VAT at 20%)

Approx shipping weight 36kg

OHV 15.5HP vertical crankshaft engine
Splash oil lubrication without oil filter
9A charging circuit, electric start, AVS. 1" dia crankshaft. Supplied without exhaust.(see below for muffler and adaptor)
31E6072116B1CC7001

Click for engine line drawings pdf


15.5HP 4155 Intek Vertical Crankshaft Engine Pressure Lube


Quantity:

15.5HP 4155 Intek Vertical Crankshaft Engine Pressure Lube


Price: 859.20 (Including VAT at 20%)

Approx shipping weight 36kg

Intek OHV 15.5HP vertical crankshaft engine
Pressure oil lubrication with filter
9A charging circuit, electric start, AVS. 1" dia crankshaft. Supplied with exhaust
31E6772117B1CC7001

Click for engine line drawings pdf


795998 Muffler


Quantity:

795998 Muffler


Price: 51.00 (Including VAT at 20%)

Approx shipping weight 600g

Exhaust muffler. Includes manifold adaptor tube

Intek 17.5HP 4175  Vertical Crankshaft Engine without Oil filter


Quantity:

Intek 17.5HP 4175 Vertical Crankshaft Engine without Oil filter


Price: 685.20 (Including VAT at 20%)

Approx shipping weight 34kg

Intek OHV 17.5 HP vertical crankshaft engine
1" diameter crankshaft. 9A charging circuit. Fuel pump. Splash lubrication
Supplied with exhaust
31G7073026G5CC1001


Click for engine line drawings pdf


Intek 17.5HP 4175  Vertical Crankshaft Engine with Oil Filter


Quantity:

Intek 17.5HP 4175 Vertical Crankshaft Engine with Oil Filter


Price: 910.80 (Including VAT at 20%)

Approx shipping weight 34kg

Intek OHV 17.5 HP vertical crankshaft engine
1" diameter crankshaft. 9A charging circuit. Fuel pump. Pressure lubrication and oil filter
Supplied with exhaust
31R7770010B1CC0001

Click for engine line drawings pdf


Intek 21HP 5210  Vertical Crankshaft Engine


Quantity:

Intek 21HP 5210 Vertical Crankshaft Engine


Price: 810.00 (Including VAT at 20%)

Approx shipping weight 34kg

Intek OHV21 HP single cylinder vertical crankshaft engine
1" diameter crankshaft. 9A charging circuit. Fuel pump. Pressure lube with oil filter
Supplied with exhaust.
3319770001G1CC1001

Click for engine details pdf


Oil Drain Extension 796530/796532


Quantity:

Oil Drain Extension 796530/796532


Price: 17.16 (Including VAT at 20%)

Approx shipping weight 140g

Extended oil drain pipe kit
Allows easier oil draining away from bodywork etc.
Includes 796530 drain pipe and 796532 Connector
Pipe can be clipped up out of the way when not in use
Can be retro fitted to any engine with 3/8" Pipe thread (approx 17mm thread outside diameter)


697761 Short Block #1


Quantity:

697761 Short Block #1


Price: 380.40 (Including VAT at 20%)

Approx shipping weight 18.5kg

Complete short block assembly for 31 series(model number starts with 31), and 28 series overhead valve, vertical crankshaft engines WITHOUT oil filter. Fitted to ride on lawnmowers, garden tractors etc.
Comes with head gasket set
(Carburettor, ignition, cylinder head, throttle linkage etc. to be removed from the old engine.)
We strongly recommend using the appropriate manual (276781 or 272147 shown below) when carrying out this work

Please note: The flywheel bolt torque requirement has been increased to 110ft lbs
19433 Strap Wrench (further down this page) or a similar suitable flywheel holding device must be used in order to safely achieve this torque figure when tightening down the flywheel
Click for more information

697762 Short Block


Quantity:

697762 Short Block


Price: 409.20 (Including VAT at 20%)

Approx shipping weight 19kg

Short block to fit 31 & 28 Series OHV engines WITH pressure lubrication and oil filter.(filter not included, see below)
Includes required gaskets etc. for equipment transfer
Please enquire with your model and type numbers prior to ordering to be sure that this is correct
(Carburettor, ignition, cylinder head, throttle linkage etc. to be removed from the old engine.)
We strongly recommend using the appropriate manual (276781 or 272147 shown below) when carrying out this work
Please note: The flywheel bolt torque requirement has been increased to 110ft lbs
19433 Strap Wrench (further down this page) or a similar suitable flywheel holding device must be used in order to safely achieve this torque figure when tightening down the flywheel

795446 Short Block


Quantity:

795446 Short Block


Price: 409.20 (Including VAT at 20%)

Approx shipping weight 17kg

Short block for 33 series vertical crankshaft engine
Includes necesary gaskets
(Carburettor, ignition, cylinder head, throttle linkage etc. to be removed from the old engine.)
We strongly recommend using the appropriate manual (276781 shown below) when carrying out this work. Oil filter not included. This needs purchasing seperately

Please note: The flywheel bolt torque requirement has been increased to 110ft lbs
19433 Strap Wrench (further down this page) or a similar suitable flywheel holding device must be used in order to safely achieve this torque figure when tightening down the flywheel

222698S Briggs & Stratton Spare Parts Flywheel key


Quantity:

222698S Briggs & Stratton Spare Parts Flywheel key


Price: 2.70 (Including VAT at 20%)

Approx shipping weight 5g

Flywheel key to fit most engines
Approx. 14mm long x 3mm x 4mm
!!<>!!Associated special tools

Oil Filter 492932S


Quantity:

Oil Filter 492932S


Price: 11.04 (Including VAT at 20%)

Approx shipping weight 300g

Briggs and Stratton spares Oil filter for many pressure lubricated engines
Approx 6cm tall x 7.5cm diameter(at base)

19433  Flywheel Strap Wrench


Quantity:

19433 Flywheel Strap Wrench


Price: 64.72 (Including VAT at 20%)

Approx shipping weight 690g

Large heavy duty strap wrench. To hold flywheel whilst loosening/torquing nut
Forged handle approx 40cm long for achieving high torque with ease
Suits all engines
Replaces 19167 flywheel holder

Briggs and Stratton Single Cylinder OHV Repair Manual 276781


Quantity:

Briggs and Stratton Single Cylinder OHV Repair Manual 276781


Price: 18.99

Approx shipping weight 510g

Repair manual for all single cylinder OHV engines other than Vanguard
(Intek, Diamond, Europa etc.)
For Vanguard engines order 272147

Covers all you need to know!

Briggs and Stratton Single Cylinder Vanguard Repair Manual 272147


Quantity:

Briggs and Stratton Single Cylinder Vanguard Repair Manual 272147


Price: 18.99

Approx shipping weight 680g

Repair manual for all single cylinder Vanguard engines

Covers all you need to know!

23HP 8230 Intek Twin Vertical Engine


Quantity:

23HP 8230 Intek Twin Vertical Engine


Price: 1,246.80 (Including VAT at 20%)

Approx shipping weight 37kg

Intek Overhead valve, V twin vertical crankshaft engine
16A Charging cuircuit, Fuel pump, Pressure lubrication with filter
1" diameter crankshaft. Supplied without exhaust
4455776135B1AF7001

Click for engine line drawings pdf


696226 Muffler


Quantity:

696226 Muffler


Price: 150.66 (Including VAT at 20%)

Approx shipping weight 3.2kg

Exhaust Muffler

16HP  Vanguard Twin Vertical Engine


Quantity:

16HP Vanguard Twin Vertical Engine


Price: 1,114.80 (Including VAT at 20%)

Approx shipping weight 31kg

16 HP Vertical crankshaft Vanguard engine
1" diameter crankshaft. 16A charging circuit
Supplied without exhaust system
3057770112B1U1001

Click for engine line drawings pdf


494057 Short Block


Quantity:

494057 Short Block


Price: 836.40 (Including VAT at 20%)

Approx shipping weight 16kg

Short block assembly for 30 Series OHV twin Vanguard
Includes gaskets etc. for fitting heads etc from the old block
Does not include oil filter (see below)
It is recommended that the manual 272144(below) is purchased for reference with this job

20HP Vanguard Twin Vertical Engine


Quantity:

20HP Vanguard Twin Vertical Engine


Price: 1,371.60 (Including VAT at 20%)

Approx shipping weight 32kg

20 HP Vertical crankshaft Vanguard engine
1" diameter crankshaft. Electric start with 16A charging circuit
Supplied without exhaust system
3587770114G1HH1001

Click for engine line drawings pdf


807752 Exhaust System


Quantity:

807752 Exhaust System


Price: 154.86 (Including VAT at 20%)

Approx shipping weight 1kg

Exhaust system for new Vanguard twin cylinder 16HP & 20HP vertical crankshaft engine
Illustration of system.

Short Block 496241


Quantity:

Short Block 496241


Price: 874.80 (Including VAT at 20%)

Approx shipping weight 28kg

Model 35 Vanguard vertical crankshaft short block. Includes all necessary gaskets etc.
It is advised to use manual 272144 to carry out this work

Briggs and Stratton Vanguard Twin Repair Manual 272144


Quantity:

Briggs and Stratton Vanguard Twin Repair Manual 272144


Price: 18.99

Approx shipping weight 466g

Complete repair manual for all Vanguard V-Twin engines
Covers everything you need to know!

23HP Vanguard Twin Vertical Engine


Quantity:

23HP Vanguard Twin Vertical Engine


Price: 1,497.60 (Including VAT at 20%)

Approx shipping weight 40kg

23HP twin cylinder Vanguard vertical crankshaft engine
1" diameter crankshaft. Electric start with 16A charging. Fuel pump
Supplied without exhaust
3867770112G1HH1001

Click for more information about this engine


Short Block 496606 for Vertical 28 Series Sidevalve Engines

The complete engine and 496606 short block for side valve engines who's model numbers begin with 28 are no longer available. The replacement engine would be the Intek 13HP OHV (see above for details). This engine is slightly different in its overall dimensions and the exhaust in on the opposite side so you would have to check it’s suitability to the application.

The alternative if feasible would be to repair your original with new parts. Once stripped down and the parts requirement is known, you can have the parts priced using the illustration and enquiry steps on the page below.

Parts Lookup and Special Orders

Briggs&Stratton uk |  Replacement engines and shortblocks

©copyright 2005 G.Campbell. All rights reserved
(see terms and conditions)

spacer image
